GSEm 8502 TBE Premium Petrol Generator

SKU: 39085020102 Categories: , Brand:

GSEm 8502 is Petrol Generator, with output max power of 5.5kW. It is equped with 220V and 400V sockets. Light and portable generator, easy to start with 8 hours working time. ATS Ready

Advantages:

• EURO 5 engine
• Heavy-duty, Strong frame, Wheels and handles
• El. and manual start
• AVR System
• Big fuel tank
• Fuel type unleaded
• 3 in 1 display (voltage/frequency/working hours)
• Low-oil level shutdown – automatic engine protection
• Circuit breaker Control
• ATS Ready
• Control panel with three sockets:
– 230V/ 16A – output 3.68 kW
– 230V/32A – output 7.5 kW
– 400V/16A – output 8.0 kW

Out of stock

18 People watching this product now!

Payment:

Weight 92 kg
Model name

GSEm 8502 TBE Premium

Max Power

8000W

Rate Power

7500W

Dual power

Yes

Voltage

230V-400V

Socket

2x230V(1x16A+1*32A)+1x400Vx16A

ATS connector

No

Voltmeter

Digital display

Over Voltage Peotector

Yes

Displacement

459cc

Start System

Electric

Fuel Capacity

25L

Run Time(75% load)

8hr

LPG

NO

Packing Dimensions (L×W×H)

700*555*560

GW/NW

102/105kg

REM Code Name Position Stock Order
39085020102
  • S001 Engine
  • S002 Air Filter Bracket
  • S003 Hexagon Flange Bolt -Large
  • S004 Muffler Paper Gasket
  • S005 Spring Washer
  • S006 Hexagon Flange Jam Nut
  • S007 Muffler
  • S008 Hexagon Flange Bolt -Large
  • S009 Hexagon Flange Bolt -Large
  • S010 Motor Mesh Strip
  • S011 Rotor
  • S012 Stator
  • S013 Motor Bracket
  • S014 Carbon Brush
  • S015 Hexagon Socket Head Bolt
  • S016 Hexagon Flange Bolt -Large
  • S017 Hexagon Socket Head Full Thread Bolt
  • S018 Terminal Block
  • S019 Hexagon Nut
  • S020 Rear Tailgate Plastic Spraying
  • S021 Avr
  • S022 Hexagon Flange Bolt
  • S023 Hexagon Flange Bolt
  • S024 Spring Washer
  • S025 Full Bridge
  • S026 Flat Washer
  • S027 Hexagon Flange Jam Nut
  • S028 Shock -Absorbing Foot
  • S029 Hexagon Flange Face Bolt -Large
  • S030 Shock Absorbing Foot
  • S031 Fuel Tank Washer
  • S032 Fuel Tank Pin
  • S033 Flat Washer
  • S034 Hexagon Flange Bolt -Small
  • S035 Fuel Tank
  • S036 Oil Level Indicator
  • S037 Cross Recessed Flat Head Screw
  • S038 Fuel Tank Screen
  • S039 Fuel Tank Cover
  • S040 Hexagon Flange Bolt -Small
  • S041 Movable Gear
  • S042 Fuel Tank Switch
  • S043 Fuel Pipe
  • S044 Pipe Clamp
  • S045 Gasoline Generator Frame Plastic Spraying
  • S046 Wheel Axle
  • S047 Wheel
  • S048 Flat Washer
  • S049 Spring Washer -Medium
  • S050 Hexagon Nut
  • S051 Bottom Foot
  • S052 Supporting Foot
  • S053 Side Insulation Plate
  • S054 Handle Cover
  • S055 5Kw Handle
  • S056 Hexagon Flange Bolt -Large
  • S057 Nylon Gasket
  • S058 Pipe Plug
  • S059 Non -Metallic Insert Hexagon Lock Nut
  • S060 Panel
  • S061 Hydraulic Circuit Breaker
  • S062 Enhanced 16A Euro Socket
  • S063 Digital Voltmeter
  • S064 Boat Switch
  • S065 Indicator Lamp
  • S066 Single -Phase Three -Hole Socket
  • S067 Socket
  • S068 Protector
  • SE01 Hexagon Flange Bolt -Small
  • SE02 Recoil Starter
  • SE03 Hexagon Flange Bolt -Large
  • SE04 Fan Cover
  • SE05 Stop Nut
  • SE06 Starting Drum
  • SE07 Fan
  • SE08 Flywheel
  • SE09 Crankcase Rubber Ring
  • SE10 Crankcase
  • SE11 Oil Drain Bolt
  • SE12 Wire Clamp
  • SE13 Isolator
  • SE14 Oil Alarm
  • SE15 Balance Shaft
  • SE16 Bearing
  • SE17 Case Paper Pad
  • SE18 Shaft Sleeve
  • SE19 Speed Control Gear
  • SE20 High Crankcase Cover
  • SE21 Oil Dipstick
  • SE22 Hexagon Flange Bolt -Large
  • SE23 Hexagon Flange Bolt-Large
  • SE24 Ignition Coil
  • SE25 Oil Seal
  • SE26 Oil Drain Bolt Gasket
  • SE27 Hexagon Flange Bolt -Large
  • SE28 Camshaft
  • SE29 Crankshaft
  • SE30 Bearing
  • SE31 Locating Pin
  • SE32 Speed Control Shaft
  • SE33 Governor Gear Spacer
  • SE34 Tappet
  • SE35 Pushrod
  • SE36 Pushrod Bracket
  • SE37 Valve Rocker Arm
  • SE38 Intake Valve
  • SE39 Exhaust Valve
  • SE40 Spring Lower Seat
  • SE41 Valve Oil Seal
  • SE42 Valve Spring
  • SE43 Valve Locking Clip
  • SE44 Valve Spring Seat
  • SE45 Top Cap
  • SE46 Connecting Rod
  • SE47 Piston Pin
  • SE48 Piston Pin Clip
  • SE49 Piston
  • SE50 Piston Ring
  • SE51 Cylinder Head Gasket
  • SE52 Locating Pin
  • SE53 Cylinder Head
  • SE54 Double Head Bolt
  • SE55 Spark Plug
  • SE56 Hexagon Flange Bolt -Large
  • SE57 Breather Gasket
  • SE58 Breather
  • SE59 Exhaust Tube
  • SE60 Screw Rubber Ring
  • SE61 Breather Metal Seal Cap
  • SE62 Breather Bolt
  • SE63 Hexagon Flange Jam Nut
  • SE64 Air Filter
  • SE65 Air Filter Paper Gasket
  • SE66 Carburetor
  • SE67 Heat Shield Paper Gasket
  • SE68 Carburetor Heat Shield
  • SE69 Air Intake Paper Gasket
  • SE70 Double Head Bolt
  • SE71 Swing Rod
  • SE72 Flat Washer
  • SE73 Oil Seal For Speed Control Rod
  • SE74 T-Bolt
  • SE75 Speed Control Fine Spring
  • SE76 Governor Rod
  • SE77 Speed Control Seat
  • SE78 Lower Windshield
  • SE79 Hexagon Flange Nut
  • SE80 Speed Control Arm
  • SE81 Swing Rod Pin
  • SE82 Speed Control Coarse Spring
