Showing all 5 resultsSorted by latest
WMEm MIG 250Di
In stock
SKU:
312502001
| MAIN SUPPLY (V/Ph Hz) |
230/1 15% 50/60 |
|---|---|
| MAX. PRIMARY CURRENT (A) |
45 |
| SETTING RANGE (A) |
40-250 |
| MAX. OUTPUT AT 100% DUTY CYCLE (MIG) A/V |
112/19,6 |
| MAX. OUTPUT AT 100% DUTY CYCLE (MMA) A/V |
90/23,6 |
| MAX. OUTPUT AT 100% DUTY CYCLE (TIG) A/V |
112/14,5 |
| RATED WORKING VOLTAGE (V) |
16-26,5 |
| OPEN CIRCUIT VOLTAGE (V) |
69 |
| POWER FACTOR AT MAX. CURRENT |
0,75 |
| EFFICIENCY (ŋ/%) |
85 |
| DIAMETER OF ELECTRODES (mm) |
1,6-4,0 |
| DIAMETER OF WIRE (mm) |
0,6-1,0 |
| PROTECTION CLASS |
IP21S |
| INSULATION CLASS |
H |
| DIMENSIONS (LxBxH cm) |
95x49x89 |
| WEIGHT (kg) |
50 |
WMEm MIG 220 DI
Out of stock
SKU:
312202001
| MAIN SUPPLY (V/Ph Hz) |
230/1 15% 50/60 |
|---|---|
| MAX. PRIMARY CURRENT (A) |
36 |
| SETTING RANGE (A) |
40-200 |
| MAX. OUTPUT AT 100% DUTY CYCLE (MIG) A/V |
89/18,5 |
| MAX. OUTPUT AT 100% DUTY CYCLE (MMA) A/V |
80/23,2 |
| MAX. OUTPUT AT 100% DUTY CYCLE (TIG) A/V |
80/13,2 |
| RATED WORKING VOLTAGE (V) |
16-24 |
| OPEN CIRCUIT VOLTAGE (V) |
69 |
| POWER FACTOR AT MAX. CURRENT |
0,75 |
| EFFICIENCY (ŋ/%) |
85 |
| DIAMETER OF ELECTRODES (mm) |
1,6-4,0 |
| DIAMETER OF WIRE (mm) |
0,6-1,0 |
| PROTECTION CLASS |
IP21S |
| INSULATION CLASS |
H |
| DIMENSIONS (LxBxH cm) |
50x22x38 |
| WEIGHT (kg) |
20 |
WMEm MIG 200D
In stock
SKU:
0312002502
| Max. diameter of electrdoe (mm) |
4 |
|---|---|
| Fuse, slow (А) |
16 |
| Open circuit voltage (V) |
68 |
| Max. outputs at 100% duty cycle, (MIG) (А) |
77 |
| Max. outputs at 100% duty cycle, (MMA) (А) |
66 |
| Max. outputs at 60% duty cycle, (MIG) (А) |
100 |
| Voltage (V) |
230 |
| Max. welding current, (MMA) (А) |
170 |
| Min. welding current, (MMA) (А) |
30 |
| Max wire Ø, unall. solid (mm) |
1 |
WMEm MIG 180 Series II
In stock
SKU:
0311802503
| Max. diameter of electrdoe (mm) |
4 |
|---|---|
| Fuse, slow (А) |
16 |
| Open circuit voltage (V) |
68 |
| Max. outputs at 100% duty cycle, (MIG) (А) |
80 |
| Max. outputs at 100% duty cycle, (MMA) (А) |
67 |
| Max. outputs at 60% duty cycle, (MIG) (А) |
104 |
| Voltage (V) |
230 |
| Max. welding current, (MMA) (А) |
150 |
| Min. welding current, (MMA) (А) |
30 |
| Max wire Ø, unall. solid (mm) |
1 |
